Cross laminated timber press NextGen


Cross laminated timber press

The XM-PRESS is a CLT press to produce a unique (longitudinally orientated) format of cross laminated timber panels. It produces according to the requirements of the EN 16351. The XM-Press is designed modular and can be produced in 2m steps (6m – 20m).

The XM-PRESS is a guarantee for accuracy, high performance and top-quality products. Prefabricated wooden walls, ceilings, roofs, whole houses, everything is possible. Make a step in the future, rediscover the wood construction.


  • Pneumatic pressure build-up
  • High loading capacity – 7,2 m³
  • Strong top pressure from 0,8 N/mm2 up to 1,2 N/mm²
  • Self-centring independent side pressure
  • Heavy-duty plastic modular belt for loading/unloading
  • Through feed design – simultaneous loading/unloading
  • Automatic sequence control possible

Benefits of pneumatic pressure buildup:

  • High force through flat tubes
  • Low and steady consumption of energy
  • No oil - no leakage
  • No heat; no radio frequency
  • Environmentally friendly
  • Low maintenance

Technical data

XM-Press 6 / 20
Pressing width 1.200 - 2.020 mm
Pressing width
Pressing thickness 60 - 600 mm
Pressing thickness
Pressing lenght 2 - 20 m
Pressing lenght
